Compression: Standard H.264 / H.265 High Profile
OS: Embedded Linux
Total number of cameras: up to 6 channels
Video Inputs: BNC × 4
TVI / AHD / CVI: 4K @ 15fps, 5MP @ 20fps, 4MP / 3MP / 1080P / 720P / WD1 @ 30fps (live)
IP Camera Quantity and Resolution: 2, max 8MP @ 25fps
HDMI × 1: 3840 × 2160/1920 × 1080/1280 × 1024/1024 × 768
VGA × 1: 1920 × 1080/1280 × 1024/1024 × 768
BNC × 1: CVBS
Audio Inputs: RCA x 1
Audio Outputs: RCA × 1
Recording Resolution: 4K / 4K Lite / 5MP / 5MP Lite / 4MP / 4MP Lite / 1080P / 720P / WD1
Number of Record Frames: 4K @ 6fps (PAL) only 1CH, 4K Lite @ 12fps (PAL), 5MP @ 12fps (PAL), 5MP Lite @ 20fps (PAL), 4MP / 3MP @ 12fps (PAL), 4MP Lite / 1080P / 720P / WD1 @ 25fps (PAL)
IP Camera Resolution: 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P
Incoming traffic: 16Mbps (Max. 40Mbps)
Outgoing traffic: 40Mbps
Network Interface: RJ45 100Mbps × 1
Network Protocols: TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP
Mobile Application: iOS, Andriod
HDD: SATA × 1, up to 6TB
RS485: RS485 × 1, for connecting a control camera or keyboard
USB: USB 2.0 × 2
Supply Voltage: DC12V
Power Consumption: Operating temperature: -10C - + 50C
