Compression: Standard H.265 High Profile
CPU: Cortex A9
OS: Embedded Linux
Video Input: BNC × 8
TVI /AHD: 8MP/5MP / 4MP / 3MP / 1080P / 720P / WD1
CVI: 4MP / 3MP / 1080P / 720P / WD1
Video IP Input: 8CH ( Up to 16CH )
HDMI × 1 : 3840 × 2160 / 1920 × 1080 / 1280 × 1024 /1024 × 768
VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
BNC × 1 : CVBS
Audio Input: RCA × 8
Audio Output: RCA × 1
Record Resolution: 4K/4Klite/5MP/5MP Lite/4MP/4MP Lite/1080P/720P/WD1
Record Frame Rate: 4K@6/7fps(PAL/NTSC), 4K Lite@12fps/15fps(PAL/NTSC), 5MP@12fps (PAL / NTSC), 5MP Lite@20fps (PAL / NTSC), 4MP@12fps(PAL) / 15fps (NTSC), 4MP Lite/1080P/720P/WD1@25fps (PAL) / 30fps (NTSC)
IP Input Resolution: 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P
IP Input Frame Rate: 25fps ( PAL ) / 30fps ( NTSC )
Playback: 8
Alarm Input: 8 CH
Alarm Output: 2 CH
Network Interface: RJ45 1000Mbps × 1
Protocol: TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP
Mobile Device: iOS, Andriod
HDD: SATA × 2, up to 8TB per HDD; E-SATA × 1
RS485: RS485 × 1, connect to PTZ or keyboard
USB: USB 2.0 × 2
Power Supply: DC12V / 4A
Consumption: ? 15W ( without HDD )
Work Environment: -10C - +50C
